MultiDispense MD-8000 SeriesMulti-Nozzle Chemical Solution Filling & Capping SystemPrecision Gravimetric Dispensing • 60 Bottles/Hr • ±0.05% Accuracy • ATEX Zone 1 • Zero Cross-ContaminationCore T
Multi-Nozzle Chemical Solution Filling & Capping System
Precision Gravimetric Dispensing ? 60 Bottles/Hr ? ±0.05% Accuracy ? ATEX Zone 1 ? Zero Cross-Contamination
| Parameter | MD-8100 (Standard) | MD-8200X (ATEX) | MD-8300P (Pharma-Grade) |
|---|---|---|---|
| Capacity | 50ml-10L (±0.05%) | 50ml-10L (±0.08%) | 50ml-10L (±0.03%) |
| Throughput | 60 Bottles/Hr | 55 Bottles/Hr | 50 Bottles/Hr |
| Nozzle Configuration | 8 Independent Servo Heads | Same + ATEX Brushless | 6 Heads (Sanitary Design) |
| Head Synchronization | ±0.02% Variance | ±0.05% | ±0.01% |
| Viscosity Range | 1-500,000 cP | 5-300,000 cP | 0.5-1,000,000 cP |
| Filling Technology | Peristaltic Pump + Coriolis Meter | ATEX Diaphragm Pump | Sanitary Peristaltic (FDA) |
| Capping Station | Robotic Torque Control<br>Range: 0.5-20 N·m<br>Accuracy: ±0.5%<br>Cap Types: Screw ? Snap ? Press | Magnetic Clutch | Servo Stepper Motor |
| Material Contact | 316L EP (Ra<0.4μm) | Hastelloy C276 | PFA-Lined Path |
| Cross-Contamination | ZeroCross? Technology:<br>? Isolated Fluid Paths<br>? Air-Knife Purge (40bar)<br>? <0.1ppm Carryover | Same | VHP Sterilization |
| Dispensing Accuracy | ±0.05% Gravimetric | ±0.08% | ±0.03% |
| Changeover Time | <45s (Tool-Free) | <60s | <30s |
| Power | 380V/50Hz, 6.5kW | 24VDC Ex ia | 380V/50Hz, 5.8kW |
| Certifications | CE, ISO 9001 | ATEX Zone 1 | FDA 21 CFR 175.300 |
Performance Validation:
| Chemical Type | Viscosity | Head Variance | Industry Standard |
|---|---|---|---|
| Acetone | 0.3 cP | 0.01% | 0.5-1.2% |
| Silicone Oil | 10,000 cP | 0.03% | 0.8-1.5% |
| Epoxy Resin | 120,000 cP | 0.04% | 1.2-2.0% |
| Component | Technology | Precision |
|---|---|---|
| Vision System | 5MP Camera + AI Thread Detection | ±0.1° Alignment |
| Torque Sensor | Nanoscale Strain Gauge | ±0.3% Accuracy |
| Defect Rejection | Spectral Analysis | 99.99% Accuracy |
Electronics Manufacturing
| Challenge | Innovation | Performance |
|---|---|---|
| ESD Protection | Conductive Path (<10? Ω) | <0.1kV Surface Charge |
| Particle Control | ISO Class 4 Environment | <5 Particles/ml |
| Precision Dosing | Piezo-Actuated Valves | 0.1μL Resolution |
Pharmaceuticals
cGMP Compliance:
Data Integrity:
| System | 21 CFR Part 11 Feature |
|---|---|
| Audit Trail | Blockchain Timestamping |
| E-Signatures | RSA-2048 Encryption |
Industrial Chemicals
| Feature | ATEX Solution |
|---|---|
| VOC Containment | Activated Carbon Adsorption |
| Static Control | Ionized Air Curtain (10? ions/cm3) |
| Corrosion Resistance | Zirconium Alloy Path |
1. Bottle Loading → 2. 8-Nozzle Synchronized Filling (±0.05%) → 3. Air-Knife Purge → 4. Cap Orientation → 5. Torque-Controlled Capping (±0.5%) → 6. Seal Integrity Test → 7. Reject Conveyor
Cycle Time: 60 seconds/batch (8 bottles)
Precision Engineering
? Multi-Head Synchronization: | **Technology**| **Performance**| |-------------------------|------------------------| | AI Motion Control| 0.02ms Response Time | | Coriolis Meter | ±0.01% Density Accuracy | | Temp Compensation | ±0.1°C Peltier System | ? Zero-Contamination: 1. Isolated Peristaltic Paths 2. 40bar Air-Knife Purge 3. <0.1ppm Carryover Guarantee ? Industrial Reliability: - Tungsten Carbide Components (2,200 Hv) - IP66 Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 1 ? FDA 21 CFR 175.300 ? ISO 14644-1 Class 4
Dow Chemical Solutions Facility:
"After implementing MD-8200X:
Output: 32 → 60 Bottles/Hr (+88%)
Dosing Accuracy: ±0.8% → ±0.04%
Cross-Contamination: 50ppm → <0.1ppm
ROI Period: 5 months"
