With the pre-configured IBC filling station that has been designed with your requirements in mind, you are able to meet all your demands in a fast and cost-effective manner. The highly flexible "
Water-Based Paint IBC Filling Station
Zero Contamination ? Precision Color Control ? Eco-Certified
| Parameter | AF-7100 (Standard) | AF-7200P (Pharma Grade) | AF-7300H (High-Volume) |
|---|---|---|---|
| Capacity | 800-1000L (±0.1%) | 800-1000L (±0.08%) | 800-1000L (±0.15%) |
| Throughput | 20 IBCs/hour | 18 IBCs/hour | 25 IBCs/hour |
| Accuracy | ±0.1% gravimetric | ±0.08% | ±0.15% |
| Viscosity Range | 50-50,000 cP | 50-30,000 cP | 50-100,000 cP |
| Filling Technology | Laminar Flow Mass Meter | Peristaltic Pump (FDA) | Dual Diaphragm Pump |
| Color Consistency | ΔE<0.4 (ISO 2813) | ΔE<0.3 | ΔE<0.5 |
| Material Contact | 316L EP (Ra<0.4μm) | 316L EP (Ra<0.2μm) | Ceramic-Coated 316L |
| Cleanability | CIP 30-min Cycle | SIP/CIP 45-min Cycle | CIP 25-min Cycle |
| Microbial Control | UV-C Light + 0.2μm Vent | 0.1μm HEPA + Ozone | UV-C + Antimicrobial Coating |
| Power | 380V/50Hz, 5.5kW | 380V/50Hz, 4.8kW | 380V/50Hz, 7.2kW |
| Water Consumption | 80L/Cycle (CIP) | 60L/Cycle (PW) | 100L/Cycle |
| Footprint (L×W×H) | 3200×2400×3000mm | 3400×2500×3200mm | 3500×2600×3100mm |
| Certifications | GREENGUARD Gold | FDA cGMP | ISO 14001 |
Color Metrics:
| Paint Type | ΔE Guarantee | Technology |
|---|---|---|
| Matte Interior | <0.4 | Shear Rate Control |
| Semi-Gloss Trim | <0.35 | Laminar Flow Nozzle |
| Metallic Basecoat | <0.5 | Flake Orientation Sensor |
| Layer | Technology | Performance |
|---|---|---|
| Air Barrier | ISO Class 5 Enclosure | <1 CFU/m3 |
| Water Barrier | 0.1μm Absolute Filter | TOC <50 ppb |
| Surface Barrier | Antimicrobial Nano-Coating | 99.99% Bioburden Reduction |
Architectural Coatings
| Feature | Specification |
|---|---|
| Sheen Consistency | Gloss Uniformity ΔGU<1.0 |
| Color Shift Prevention | UV-Filtered Lighting (D65) |
| Splash-Free Filling | Coanda Adhesion Technology |
Automotive Waterborne
VOC Compliance:
Carbon Adsorption (VOC<10g/L)
EPA Method 24 Validation Port
Metallic Control:
| Parameter | Performance |
|---|---|
| Flake Orientation | ±3° Variance Control |
| Color Match | ΔE<0.4 (D65/D50) |
Industrial Wood Coatings
| Component | Certification |
|---|---|
| GREENGUARD Gold | UL 2818 Certified |
| FDA 21 CFR 175.300 | Indirect Food Contact |
| FSC Sustainability | Chain-of-Custody Tracking |
10" HMI with AquaOS?
AI-Driven Features:
Contamination AI:
| Risk | Action |
|---|---|
| Bioburden Spike | Auto Ozone Shock |
| TOC >100 ppb | CIP Initiation |
Resource Optimizer:
| Parameter | Savings |
|---|---|
| Water Usage | ↓45% vs Conventional |
| Energy Consumption | 0.28 kWh/IBC |
? GREENGUARD Gold (UL 2818) ? FDA 21 CFR 175.300 ? ISO 9001/14001 ? EHEDG EL Class I ? EU Ecolabel
PPG Paints Case Study:
*"After 9 months using AF-7100:
Output: 14 → 20 IBCs/hour (+43%)
Color Variance: ΔE 1.2 → 0.32
Water Savings: 1,200L/day → 660L/day
ROI: 7 months"*
1. AGV IBC Loading → 2. Deionized Rinse → 3. Nitrogen Purging (O?<0.5%) → 4. Laminar Flow Filling (±0.1%) → 5. In-line Color Verification → 6. Vapor-Lock Sealing → 7. ATP Surface Test
Cycle Time: 3 min/IBC
APPLICABLE BARREL TYPE
