HeavyFill HF-10000 SeriesSemi-Automatic 1000L Chemical Liquid Filling System with Robotic Rocker ArmIndustrial-Grade Precision for Drums & IBCs • 18 Drums/Hr • ±0.15% Accuracy • ATEX/FDA Dual Comp
Semi-Automatic 1000L Chemical Liquid Filling System with Robotic Rocker Arm
Industrial-Grade Precision for Drums & IBCs ? 18 Drums/Hr ? ±0.15% Accuracy ? ATEX/FDA Dual Compliance
Performance Metrics:
| Parameter | Performance | Industry Standard |
|---|---|---|
| Positioning Accuracy | ±0.5mm (LiDAR Guided) | ±5mm |
| Container Handling | 50-1500kg Payload | Manual Adjustment |
| Cycle Time | 18s/Container | 45-60s |
| Layer | Technology | Efficiency |
|---|---|---|
| Primary Seal | Inflatable PTFE Gasket | <0.01mg/m3 VOC Leak |
| Secondary Barrier | Double Mechanical Seal | API 682 Plan 53B |
| Tertiary Defense | Vapor Recovery Unit (VRU) | 99.95% Solvent Capture |
| Parameter | HF-1010 (Standard) | HF-1020X (ATEX) | HF-1030F (Food-Grade) |
|---|---|---|---|
| Capacity | 1000L (±0.15%) | 1000L (±0.2%) | 1000L (±0.1%) |
| Throughput | 18 Drums/Hour | 16 Drums/Hour | 15 Drums/Hour |
| Flow Rate | 300L/min | 280L/min | 250L/min |
| Viscosity Range | 10-500,000 cP | 50-300,000 cP | 100-1,000,000 cP |
| Rocker Arm | 6-Axis Servo Robot<br>? 500kg Payload<br>? ±0.5mm Repeatability<br>? 360° Rotation | Same + ATEX Brushless Motors | Hygienic IP69K Design |
| Filling Technology | Mass Flow Meter + Gear Pump | ATEX Diaphragm Pump | Sanitary Peristaltic Pump |
| Material Contact | 316L EP (Ra<0.4μm) | Hastelloy C276 | Electropolished 316L (Ra<0.2μm) |
| Connection System | Auto-Sealing Quick Coupler<br>? Camlock<br>? DIN 11851<br>? Tri-Clamp | Same | Aseptic RTP Connection |
| Residual Control | <0.1L (Pneumatic Purge) | <0.08L | <0.05L |
| Changeover Time | <120s (Tool-Free) | <150s | <100s |
| Power | 480V/60Hz, 22kW | 24VDC Ex ia | 480V/60Hz, 20kW |
| Certifications | CE, ISO 9001 | ATEX Zone 2 | FDA 21 CFR 177.2600 |
Chemical Processing
| Feature | ATEX Solution | Performance |
|---|---|---|
| Explosion Safety | Nitrogen Inerting (O?<8%) | Zone 2 Compliance |
| Static Control | Ionized Air Curtain (10? ions/cm3) | <0.1kV Charge |
| Corrosion Resistance | Zirconium Coated Path | Resists HCl/HF Acid |
Food & Cosmetic
Sanitary Design:
Oxygen Barrier:
| Technology | Effect |
|---|---|
| N? Purging | O?<0.1% Headspace |
| Vacuum Filling | -0.8bar Residual Pressure |
Pharmaceuticals
| Component | cGMP Compliance |
|---|---|
| Data Integrity | 21 CFR Part 11 + Blockchain |
| Cleanability | 3D Spray Ball Coverage |
| Material Traceability | RFID/NFC Tracking |
1. Manual Container Placement → 2. Rocker Arm Auto-Engagement → 3. Sterile Connection (±0.5mm) → 4. Precision Filling (±0.15%) → 5. Pneumatic Purge → 6. Vapor Recovery → 7. Auto-Disconnect → 8. Conveyor Transfer
Cycle Time: 3.3 minutes/drum
Industrial Precision Engineering
? Robotic Positioning Mastery: | **Parameter** | **Performance**| |----------------------|------------------------| | Payload Capacity| 50-1500kg| | Repeatability | ±0.5mm| | Speed | 1.5m/s Acceleration | ? Zero-Emission Architecture: 1. Triple-Seal Connection System 2. 99.95% Efficient Vapor Recovery 3. <0.1ppm Fugitive Emissions ? Heavy-Duty Reliability: - 100,000-Hour MTBF - IP66/69K Protection - 10-Year Structural Warranty
? ATEX 2014/34/EU Zone 2 ? FDA 21 CFR 177.2600 ? EHEDG EL Class I ? CE EN 13445
BASF Antwerp Chemical Park:
"After implementing HF-1020X for solvent drums:
Output: 10 → 18 Drums/Hour (+80%)
Spill Incidents: 8/month → 0
VOC Emissions: ↓98% (VRU System)
ROI Period: 7.2 months"
