AshCap AC-8000 Series20L Automatic Ink Filling & Capping System with Triple Dust ContainmentIndustrial-Grade Precision for Pigments • Carbon Black • Fly Ash • 40 Drums/Hr • ±0.1% Accuracy • ATEX Z
20L Automatic Ink Filling & Capping System with Triple Dust Containment
Industrial-Grade Precision for Pigments ? Carbon Black ? Fly Ash ? 40 Drums/Hr ? ±0.1% Accuracy ? ATEX Zone 22 Certified
| Parameter | AC-8100 (Standard) | AC-8200X (ATEX) | AC-8300F (Food-Grade) |
|---|---|---|---|
| Capacity | 20L (±0.1%) | 20L (±0.15%) | 20L (±0.08%) |
| Throughput | 40 Drums/Hr | 36 Drums/Hr | 35 Drums/Hr |
| Material Compatibility | Inks ? Pigments ? Carbon Black ? Fly Ash ? Toner | Explosive Dusts | Food Colorants |
| Filling Accuracy | ±0.1% Gravimetric | ±0.15% | ±0.08% |
| Filling Technology | Twin-Screw Auger + Coriolis Meter | ATEX Gear Pump | Peristaltic Pump (FDA) |
| Dust Containment | TripleShield? System:<br>1. -40Pa Vacuum Hood<br>2. H14 HEPA Filtration<br>3. Ionized Air Curtain | + Nitrogen Inerting | + UV-C Sterilization |
| Capping Technology | Robotic Torque Control:<br>? 5-100 N·m Range<br>? ±0.5% Accuracy<br>? Auto Thread Detection | Magnetic Clutch System | Servo Stepper Motor |
| Material Contact | Hardox 500 + Tungsten Carbide | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| Cap Types | Screw ? Press ? Lug ? Child-Resistant | Same + Vapor-Barrier | Tamper-Evident |
| Changeover Time | <75s (Tool-Free) | <90s | <60s |
| Power | 380V/50Hz, 7.5kW | 24VDC Ex ia | 380V/50Hz, 6.8kW |
| Certifications | CE, ISO 9001 | ATEX Zone 22 | FDA 21 CFR 175.300 |
Performance Validation:
| Material | Dust Emission | OSHA Limit | Containment Efficiency |
|---|---|---|---|
| Carbon Black | 0.6mg/m3 | 3.5mg/m3 | 99.8% |
| Fly Ash | 0.9mg/m3 | 15mg/m3 | 99.4% |
| Iron Oxide Pigment | 0.7mg/m3 | 10mg/m3 | 99.6% |
| Component | Technology | Precision |
|---|---|---|
| Torque Control | Strain Gauge Feedback | ±0.5% of Set Value |
| Thread Alignment | LiDAR 3D Scanning | ±0.3° Angular Error |
| Defect Detection | 5MP AI Vision System | 0.2mm Flaw Recognition |
Printing Inks & Pigments
| Challenge | Innovation | Performance |
|---|---|---|
| Color Consistency | In-line Viscosity Control | ±2% Brookfield |
| Settling Prevention | Pulsed Ultrasonic Agitator | 99.8% Uniformity |
| Static Control | Ionized Air Curtain (10? ions/cm3) | <0.5kV Surface Charge |
Fly Ash & Carbon Black
Explosion Safety:
Abrasion Resistance:
| Component | Material | Lifespan |
|---|---|---|
| Auger | Tungsten Carbide (2,200 Hv) | 50,000 Hours |
| Nozzle | Alumina Ceramic (1,800 Hv) | 100,000 Hours |
Food Colorants
| Feature | EHEDG Compliance |
|---|---|
| Cleanability | Ra<0.4μm Electropolished |
| Material Safety | FDA 21 CFR 175.300 |
| Allergen Control | Dedicated Change Parts |
**10" HMI with InksOS?**
AI-Driven Features:
Quality Sentinel:
| Parameter | Action |
|---|---|
| Color Shift ΔE>0.5 | Flow Adjustment |
| Density Variance >1% | Formula Correction |
Zero-Downtime:
| Component | Alert Threshold |
|---|---|
| Auger Wear | Torque >120% Baseline |
| Filter Saturation | ΔP >0.6bar |
Precision Engineering
? Dust-Free Guarantee: | **Technology**| **Performance**| |-------------------------|------------------------| | HEPA H14 Filtration | 99.97%@0.3μm (EN 1822) | | Negative Pressure| -40Pa ±2Pa| | Ionized Air Curtain| 10? ions/cm3 Output| ? Capping Perfection: 1. ±0.5% Torque Accuracy 2. 0.2mm Thread Defect Detection 3. <3s Cap-Type Changeover ? Extreme Durability: - Tungsten Carbide Auger (2,200 Hv) - IP69K Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 22 ? FDA 21 CFR 175.300 ? ISO 9001:2015
BASF Printing Inks Division:
"After implementing AC-8200X:
Output: 22 → 40 Drums/Hr (+82%)
Dust Emissions: 18mg/m3 → 0.7mg/m3
Cap Defect Rate: 3.2% → 0.05%
ROI Period: 6 months"
APPLICABLE BARREL TYPE
